Electric Control Cut To Length Line With PLC Contolled 28 Tons
Electric Control Cut To Length Line Advantage
Cut to length production is an industry which need qualified machine and experienced technology link together to produce the products, that means the machine and experience are both important, our company are only cut to length
Electric Control Cut To Length Line With PLC Contolled 28 Tons design information
Electric Control Cut To Length Line Advantage
Cut to length production is an industry which need qualified machine and experienced technology link together to produce the products, that means the machine and experience are both important, our company are only cut to length machine manufacture whom use self-machine to produce steel sheet in large quantity, we are improving our machine with running them to get experienced technology. Choose us, you are not only get the machine from us, you are also get he experienced technology from us.
Market distribution
At the beginning, we are manufacturing and selling the cut to length machine at domestic market only, during the opening and development of country policy, also with the improvement of the technology, we are start the export of the machinery since 2006, and now the cut to length Machine has been export to more than 70 countries, the main market like Asia, North America, South America, Europe, Middle East, Southeast Asia and Africa. We are getting reputed in the world market.
Cut to length machine production process
According to different customer, the machinery consist by different process, but our company having the standard production process as blew, this is for your reference, suppose your company have special requirement, we could discuss and make your special design.
Carrying coil car — Decoiler — Gantry type guiding bracket, pressing- Shovel head- Pair pinching roller,three rollers first leveling — Deviation rectification in middle — Main leveling machine,encoder — Tail plate pinching — Hydraulic brake type shearing machine — Loading material car — Hydraulic control — Electric control
Cut to length machine specification
Accordingly to the market demands. We are given the standard models as blew, and this is for your reference only, the production range and main technical can be adjustable suppose your company have special requirement.
| 1 | raw material | cold rolled steel, galvanzied steel, coated steel |
| 2 | Shteet thickness | 1mm-6mm |
| 3 | Sheet width | 400mm-1600mm/1800mm/2000mm |
| 4 | Coil ID | 508mm |
| 5 | Coil OD | 1800mm |
| 6 | Coiler Weight | 28 Tons |
Cut to length production is an industry which need qualified machine and experienced technology link together to produce the products, that means the machine and experience are both important, our company are only cut to length machine manufacture whom use self-machine to produce steel sheet in large quantity, we are improving our machine with running them to get experienced technology. Choose us, you are not only get the machine from us, you are also get he experienced technology from us.
Market distribution
At the beginning, we are manufacturing and selling the cut to length machine at domestic market only, during the opening and development of country policy, also with the improvement of the technology, we are start the export of the machinery since 2006, and now the cut to length Machine has been export to more than 70 countries, the main market like Asia, North America, South America, Europe, Middle East, Southeast Asia and Africa. We are getting reputed in the world market.
Cut to length machine production process
According to different customer, the machinery consist by different process, but our company having the standard production process as blew, this is for your reference, suppose your company have special requirement, we could discuss and make your special design.
Carrying coil car — Decoiler — Gantry type guiding bracket, pressing- Shovel head- Pair pinching roller,three rollers first leveling — Deviation rectification in middle — Main leveling machine,encoder — Tail plate pinching — Hydraulic brake type shearing machine — Loading material car — Hydraulic control — Electric control
Cut to length machine specification
Accordingly to the market demands. We are given the standard models as blew, and this is for your reference only, the production range and main technical can be adjustable suppose your company have special requirement.
| Cut to Length Line Specification | |||
| Mill Model |
Width (mm) |
Thickness range(mm) |
Speed (m/min) |
| FJY0.2-2*800/1250/1600 | 300-800/1250/1600 | 0.2-2 | 70-100 |
| FJY0.5-3*800/1250/1600 | 300-800/1250/1600 | 0.5-3 | 70-90 |
| JPY0.3-2.0*800 | 200-800 | 0.3-2.0 | 0-60 |
| JPY0.3-2.0*1250/1600 | 300-1250/1600 | 0.3-2.0 | 0-60 |
| JPY0.5-3.0*1250/1600/2000 | 400-1250/1600/2000 | 0.3-3.0 | 0-60 |
| JPY1.0-6.0*1250/1600 | 800-1600 | 1.0-6.0 | 0-35 |
| JPY2.0-10.0*1600/2000 | 800-1600 | 2.0-10.0 | 0-35 |
| JPY3.0-12.0*1600/2000 | 800-2000 | 3.0-12.0 | 0-25 |
| JPY4.0-16.0*1600/2000 | 1000-2000 | 4.0-16.0 | 0-25 |
| JPY8.0-25.0*1600/2000 | 1000-2500 | 8.0-25.0 | 0-20 |
